Motor complete only for replacement (4.623-871.0)
| П-п | Название | Подбор (запрос наличия и цен) |
|---|---|---|
| 2 | Bearing cover B | |
| 3 | Washer | |
| 4 | Wobble plate -nur für Ersatz- | |
| 7 | Screw plug | |
| 8 | Blower wheel | |
| 9 | Tolerance ring 62x10 | |
| 10 | Taper roller bearing | |
| 11 | Ball bearing 6305-2Z | |
| 12 | O-Ring seal 11x2,2 NBR 70 | |
| 17 | Metal bonding agent | |
| 21 | Self-tapping screw M6x25 | |
| 25 | Cylinder head screw M8x20 -8.8-A2E ISO | |
| 27 | Toothed lock washer A8,4-FSt-PH DIN 6797 | |
| 30 | Parallel key A 5x5x25-C45K DIN 6885 | |
| 31 | Parallel key 6x6x25 -C45K DIN 6885-1 | |
| 32 | Radial shaft seal ring A35x52x7-NBR DIN |
